Principais Características e Aplicações
Opções de Largura Versáteis: A linha é oferecida em várias larguras, permitindo que os fabricantes escolham o tamanho ideal para suas necessidades específicas de produção. Essa flexibilidade é ideal para lidar com diferentes tamanhos de papel e acomodar várias especificações de produtos.
Processo em Duas Etapas: O processo de impregnação em duas etapas garante um penetração completa da resina e uma cura ideal, resultando em papel de melamina de alta qualidade com excelente durabilidade e propriedades de superfície.
Ampla Gama de Aplicações:
| Paper width | Max 1350 mm, 1250 mm |
| Mechanical Speed | 0-40m/min 0-60m/min in different models |
| Operating Speed | 15‐25m/min @80gsm & 100% glue pick‐up; Operating Speed subjects to resin and paper property. |
| Operating Level | 1380mm 1250mm or customized operating level |
| Rollers Max Width | 1500mm |
| Nozzle width | 1500mm |
| Paper Loading Max Ø | Ø1200mm bearing 1.2Tons paper weight |
| Paper Loading Max Weight | 1200kg |
| Air Expanding Core Dimension Ø | Ø76mm |
| Resin Sorts | MF/UF/PF, suitable for melamine paper, phenolic paper, |
| Resin Solids Contents Property | ≥55% |
| Resin Content by Curtain Roller Control | 60‐200%, ±2% |
| Glue Volatility | 4.5 ‐ 7.5% |
| Drive side /direction | Left or Right, seen from feeding direction, or Customized |
| Operator side /direction | Left or Right, seen from feeding direction, or Customized |
| Nos of Oven Chambers | Nos of 6segments, 3.75m oven, or 8segmenst, subject to speed requirement |
| Nos. of Temperature control | 6pcs |
| Max Circulating Air | Approx. 12000M3/hr. adjustable |
| Max Exhausting Gas | Approx. 11500M3/hr. adjustable |
| Average Exhausting Gas | Approx. 5000M3/hr. adjustable |
| Heating Sources | Thermal oil liquid |
| Drying temperature of chambers | 50-180 0C adjustable |
| Power supply | 3PH AC220/380/415V - 50/60Hz -2PH AC 220V |
| Total installation Power | Approx. 55Kw |
| Tower Efficiency | 50-70%, operating power capacity as 25-30Kw |
| Compressed Air | Approx. 1.5M3/min -0.6Mpa |
| Cooling water circulation | Approx. 3M3/hr, 0.1-0.3Mpa at 100C, final web temperature 20 0C, requirement cooling Tower by buyer |
| Doctor Rollers φ | φ 290mm |
| Doctor Rollers Linear tolerance | 0.002mm |
| Brinell Hardness | 510-570 HB |
| Doctor Rollers Tolerance | 0.05μm |
| Glue Pickup tolerance | ±3% |
| Temperature controlling accuracy | ±1 0C |
| Cutting Accuracy | ±0.5mm |
| Noise level in 1meter distance | less than 80 dB |
